Double Loop Slitter

· Manufacture :

  -. Year : July 19. 2000

  -. Company : Sonoda Engineering Co., Ltd. ( Osaca Japan )

· Type : Double Loop

· Mode : Drive & Pull ( Conbination )

· Pass Direction : Right to Left

· Revamping

  -. Year : 2019. 12

  -. Company : Dongshin Tech ( Korea )

  -. Details of Revamping : Electric Control System

· Working Data

  -. Material

  -. Thickness

  -. Width

  -. Uncoiler Inside Dia

  -. Uncoiler Outside Dia

  -. Uncoil Weight

  -. Recoiler Inside Dia

  -. Recoiler Outside Dia

  -. Line Speed

  -. Threading Speed

  -. Minimum Width

· Winding Direction : Upper Winding

· Line Data

· Uncoiler

  -. Driven Motor : AC 1.5Kw Geared

  -. Drum Dimension : 400/500 mmΦ X 795 mm Face

  -. Air Disk Brake, Driven Snubber Roll ( AC 0.75Kw Geared Motor )

· Driven Pinch Roll for Entry Control

  -. Driven Motor : VS 7.5Kw

  -. Dimension : 180 mmΦ X 550mmL, Urethane Coated, Air Up-Down

  -. Speed : Feeding Speed : 10 MPM, Threading Speed : 15 MPM

· Cutter Stand

  -. Driven Motor :AC 30Kw 4Pole

  -. Reduction Ratio : 8.06 : 1

  -. Arbor Dimension : 100 mmΦ X 650mmL Surface Hardened & Grinding

  -. Cutter Dimension : 180 mmΦ X 100 mmΦ X 7.5mmt & 3mmt

  -. Cutter Guiding Method : Finger

· Recoiler

  -. Driven Motor : DC 22Kw 400/1600

  -. Drum Dimension : 200/300 ( 200 + attachment ) & 400/500 ( 400 + attachment )

  -. Coil Weight : 2,000Kg

· Composition

  a. Uncoiler driven by Motor, with Driven Snubber Roll.

  B. Coil Openning Table

  c. Driven Pinch Roll & Shear

  d. Entry Looper with By Pass Table

  e. Driven Pinch Roll

  f. Cutter Stand

  g. Exit Looper with By Pass Table

  h. Disk Seperator

  i. Driven Pinch Roll & Shear

  j. Deflector Roll with Guide Table

  k. Recoiler with Over Arm Seperator

**The specifications presented include unverified and estimated parts.**

**The price is quoted as is where is at the time of sale.**

**All specifications are subject to verification by purchaser**
