CNC image measuring device - Mitutoyo QVX1H606-PRO_BHU2G
Product Specifications
Maker Mitutoyo
Model QVX1H606-PRO_BHU2G
Category Measuring Instruments ・ Instruments
Model year 2004
Condition Used
Showroom Information
Exhibition hall Kyushu Technical Center
Price & Inquiry
price Price Inquiry
Inquiry Number HB1172
Product Overview
Mitutoyo QVX1H606-PRO_BHU2G is a used Measuring Instruments ・ Instruments item available from ASKINDEX Korea. It is kept in stock at our Kyushu Technical Center showroom, so stock checks and price quotations are available immediately. You can also compare other used products from the same manufacturer (Mitutoyo) and the same category (Measuring Instruments ・ Instruments).
Mechanical Specifications
Measuring range X-axis, Y-axis, Z-axis
LI-HU measuring range 476x650x250
CCD measurement range 600x650x250
Minimum display amount 0.1?
Stage glass size W697 D758
Maximum measurement amount 50kg
External dimensions: W1310 D1843 H1790
Weight 1650kg
Current QV Hybrid Type ① equivalent
Attachments
※ Click on the image below to zoom in.
