- Shinkwang Tech ( Korea ) Welding Connection Method

Product Overview

Shinkwang Tech ( Korea ) Welding Connection Method is a used Factory Equipment-Related item available from ASKINDEX Korea. It is kept in stock at our etc showroom, so stock checks and price quotations are available immediately. You can also compare other used products from the same manufacturer (Shinkwang Tech ( Korea )) and the same category (Factory Equipment-Related).

· Manufacturer :

  -. Year : 2019. 04

  -. Company : Shinkwang Tech ( Korea )

· Type : Welding Connection Method

· Pass Direction : Left to Right

· Working Data

  -. Thickness : 3.0 - 1.0 mm

  -. Width : 450 mm

  -. Coil Weight : 3,000 Kg

  -. Speed : Max 45 m/min

· Line Data

· Uncoiler

  -. Coil Dia : 508 - 1200mmΦ

  -. Motor : AC 40Hp 6 Pole

  -. Reduction Rate : 10.14 : 1

· Recoiler

  -. Coil Dia : 508 - 1200mmΦ

  -. Motor : AC 40Hp 6 Pole

  -. Reduction Rate : 40.56 : 1

· Composition

  a. Uncoiler with Snubber Roll & Guide Pressure Roll

  b. Deflecter Roll with Guide Plate

  C. Cramp operated by Air

  d. Side Guide

  e. Pinch Roll driven by 1 Hp Geared Motor

  f. Shear operated by Hydraulic

  g. Entry Pressure Board operated by Hydraulic

  h. Welder ( TIG )

  i. Exit Pressure Board

  j. Cramp operated by Air

  k. Deflector Roll

  l. Recoiler with Snubber Roll

**The specifications presented include unverified and estimated parts.**

**The price is quoted as is where is at the time of sale.**

**All specifications are subject to verification by purchaser**
