High-precision laser position measurement sensor (controller) - Azbil K1G-C04
Product Specifications
Maker Azbil
Model K1G-C04
Category Measuring Instruments ・ Instruments
External Dimensions W48D140H95
Condition Used
Showroom Information
Exhibition hall Kyushu Technical Center
Price & Inquiry
price Price Inquiry
Inquiry Number N30836
Product Overview
Azbil K1G-C04 is a used Measuring Instruments ・ Instruments item available from ASKINDEX Korea. External dimensions: W48D140H95. It is kept in stock at our Kyushu Technical Center showroom, so stock checks and price quotations are available immediately. You can also compare other used products from the same manufacturer (Azbil) and the same category (Measuring Instruments ・ Instruments).
Mechanical Specifications
Connected sensor: K1G-S□□
Number of connected sensors: 4
Minimum display unit: 0.1μm
Measurement cycle: 250μs/500μs/1ms
Analog output: 4 points
Digital output: 8 points
Digital input: 4 points
Power supply: DC12~24V
