Fiber sensor amplifier (parent unit/one-line slave unit) - Keyence FS-V11/V12

Product Overview

Keyence FS-V11/V12 is a used Other item available from ASKINDEX Korea. It is kept in stock at our Tsuru Technical Center showroom, so stock checks and price quotations are available immediately. You can also compare other used products from the same manufacturer (Keyence) and the same category (Other).

Mechanical Specifications

・FS-V11 Type: Parent unit

Output type: NPN output

Light source: Red LED

Response time: 250 µs (FINE) / 500 µs (TURBO) / 1 ms (SUPER TURBO)

Addition of additional handsets: Up to 16 units possible (total of 17 base units connected)*1

Number of interference prevention units: FINE: 4 units, TURBO/SUPER: 8 units

Power supply voltage: DC 12 - 24 V ±10%, ripple (PP) 10% or less

Current consumption: 50 mA or less

・FS-V12 Type: One-line handset

Output type: NPN output

Light source: Red LED

Response time: 250 µs (FINE) / 500 µs (TURBO) / 1 ms (SUPER TURBO)

Control output: NPN open collector, maximum 100mA (40V or less), residual voltage 1V or less

Addition of additional handsets: Up to 16 units possible (17 units total connected to the main unit)

Number of interference prevention units: FINE: 4 units, TURBO/SUPER: 8 units

Power supply voltage: DC 12 - 24 V ±10%, ripple (PP) 10% or less

Current consumption: 50 mA or less

*Quantity in stock: 3 sets
