Turbomolecular Pump Set - Edwards STP-H451CV/SCU-800
Product Specifications
Maker Edwards
Model STP-H451CV/SCU-800
Category Pump
External Dimensions Φ180 D130 H232
Condition Used
Showroom Information
Exhibition hall Kyushu Technical Center
Price & Inquiry
price Price Inquiry
Inquiry Number NC1055
Product Overview
Edwards STP-H451CV/SCU-800 is a used Pump item available from ASKINDEX Korea. External dimensions: Φ180 D130 H232. It is kept in stock at our Kyushu Technical Center showroom, so stock checks and price quotations are available immediately. You can also compare other used products from the same manufacturer (Edwards) and the same category (Pump).
Mechanical Specifications
Intake flange: ISO160 (outer diameter: 180)
Exhaust port: NW40
Ultimate pressure: 10-7Pa
Exhaust speed: 450L/s (N2)
Rated speed: 48,000 rpm
Installation position: Free
Power supply: AC100-120/200-240V
Frequency: 50/60HZ
Connector cable length: 3m
Power cable included
*Air intake: Discolored
*Exhaust port: dirty
Attachments
※ Click on the image below to zoom in.
