Temperature Controller - Azbil C36TC0UA1200
Product Specifications
Maker Azbil
Model C36TC0UA1200
Category Parts Related
External Dimensions W96 D73 H96
Condition Used
Showroom Information
Exhibition hall Kyushu Technical Center
Price & Inquiry
price Price Inquiry
Inquiry Number P30698
Product Overview
Azbil C36TC0UA1200 is a used Parts Related item available from ASKINDEX Korea. External dimensions: W96 D73 H96. It is kept in stock at our Kyushu Technical Center showroom, so stock checks and price quotations are available immediately. You can also compare other used products from the same manufacturer (Azbil) and the same category (Parts Related).
Mechanical Specifications
*Unused item
Power supply voltage: AC100-240V (50/60Hz)
(Control output)
Control output 1: Current output
Control output 2: None
Indication accuracy: ±0.1%FS±1digit
Sampling period: 100 ms
Panel size: 96 x 96 mm
Event relay output: 3 points
Current transformer input: 2 points
Digital input: 4 points
Display method: 4-digit digital, 7-segment LED display
(PV: top green / SP: bottom orange)
Power consumption: up to 12VA
Control action: ON/OFF control, time proportional PID, current proportional PID
Attachments
※ Click on the image below to zoom in.
