DC voltage/current source/monitor - ADC 6240B
Product Specifications
Maker ADC
Model 6240B
Category Measuring Instruments ・ Instruments
External Dimensions W245 D420 H90
Condition Used
Showroom Information
Exhibition hall Enzan Technical Center
Price & Inquiry
price Price Inquiry
Inquiry Number P90159
Product Overview
ADC 6240B is a used Measuring Instruments ・ Instruments item available from ASKINDEX Korea. External dimensions: W245 D420 H90. It is kept in stock at our Enzan Technical Center showroom, so stock checks and price quotations are available immediately. You can also compare other used products from the same manufacturer (ADC) and the same category (Measuring Instruments ・ Instruments).
Mechanical Specifications
Main unit only
Generation and measurement range
Voltage: 0 to ±15 V, Current: 0 to ±4 A (DC is 1 A)
Basic accuracy: ±0.02% of source and measurement
5.5 digits (±319999), 1 μV/100 pA resolution measurement
Capable of sourcing/sinking ±4 A for up to 20 ms
Pulse measurement with a minimum pulse width of 50 μs and a resolution of 1 μs
Power supply AC100V 50/60Hz (power cable included)
Attachments
※ Click on the image below to zoom in.
