Mirror mount - Newport New Focus 9807
Product Specifications
Maker Newport
Model New Focus 9807
Category R&D of Physical ・ Chemical Equipment
External Dimensions W55 D55 H35
Condition Used
Showroom Information
Exhibition hall Enzan Technical Center
Price & Inquiry
price Price Inquiry
Inquiry Number Q40351
Product Overview
Newport New Focus 9807 is a used R&D of Physical ・ Chemical Equipment item available from ASKINDEX Korea. External dimensions: W55 D55 H35. It is kept in stock at our Enzan Technical Center showroom, so stock checks and price quotations are available immediately. You can also compare other used products from the same manufacturer (Newport) and the same category (R&D of Physical ・ Chemical Equipment).
Machine specifications
Type: Standard Mechanism: Kinematics
Optical diameter: 25.4 mm Number of actuators: 3
Actuator drive: Knob Actuator lock: No
Adjustment screw thread count: 80TPI Adjustment: z, θx, θy
Sensitivity: 4.4 arcseconds Angle range: ±4°
Actuator orientation: Left-handed; Optical load: Front
Material: Aluminum; Drive system: Knob, non-locking type
Screw type: 8-32 (M4) CLR Optical axis height: 25.4 mm
Optical mount: Set screw
